Technical Parameters:
| Model | BDF-25V100 | BDF-25V270 | BDF-25V350 | BDF-25V936 | ||||
| Capacity | 100L | 270L | 350L | 936L | ||||
| Temp. Range | -10~-25℃ | |||||||
| Temp. Accuracy | 0.1℃ | |||||||
| Temp. Uniformity | ≤3℃ | 5℃ | ||||||
| Temp. Stability | ≤3℃ | 5℃ | ||||||
| Recovery Time
(Recover to -22℃ in an ambient temp. of 25℃) |
≤15min | |||||||
| Cooling Time
(Cool down to -25℃ in an ambient temp. of 25℃) |
≤1.5h | 150min | ||||||
| Control System | Microprocessor control | |||||||
| Display | LED | |||||||
| Alarm | High and low temperature alarm, power failure alarm, thermostat fault alarm, door switch alarm | High and low temperature alarm, thermostat fault alarm, door switch alarm, power failure alarm(8h) | High and low temperature alarm, sensor fault alarm, thermostat fault alarm, power off alarm, door opening alarm, ambient temperature alarm, condenser fault alarm, filter check alarm, abnormal voltage alarm, low battery power alarm | |||||
| Refrigeration Type | Direct-cooling | |||||||
| Refrigerant | R600a/48g | R290/65g | R290/85g | R404A/320g | ||||
| Compressor | International famous brand compressor /1 | Imported brand SECOP compressor/2 | ||||||
| Condenser & Evaporator | Side-panel type Bundy tube condenser; wire-on-tube Bundy tube evaporator | Wire-on-tube Bundy tube condenser;
Built-in coil type copper tube evaporator |
Finned copper tube condenser; built-in coil type copper tube evaporator | |||||
| Defrost | Manual defrost | |||||||
| Construction | Polyurethane cyclopentane foam | |||||||
| Material | Internal Material | HIPS | 304 stainless steel | |||||
| External Material | Precoated steel plate | Sprayed steel plate | ||||||
| Door | Outer door: cyclopentane integral foam outer door*1
Interior door: / |
Outer door: cyclopentane integral foam outer door*1
Interior door: sprayed steel plate door*4 |
Outer door: cyclopentane integral foam outer door*1
Interior door: sprayed steel plate door*5 |
Outer door: sprayed steel plate outer door*1
Interior door: 304 stainless steel door*4 |
||||
| Consumption | 100W | 332W | 312W | 1000W | ||||
| Power Supply | AC 220V, 50Hz(Standard); 110/220V, 60Hz(Optional) | AC 220V, 50Hz(Standard); 220V, 60Hz; 110V, 50/60Hz(Optional) | ||||||
| Casters | No | Yes | ||||||
| Shelf | 3(Drawer) | 3 | 4 | 3 | ||||
| Standard Accessory | Test hole | Test hole, USB interface | Test hole | |||||
| Optional Accessory | Temperature recorder | Temperature recorder, RS485, printer, inner door | Temperature recorder, liquid nitrogen backup system, remote alarm function interface, USB interface | |||||
| Internal Size (W*D*H) | 410*440*630mm | 520*567*1013mm | 520*567*1266mm | 1000*700*1335mm | ||||
| External Size (W*D*H) | 600*620*870mm | 690*744*1631mm | 690*744*1885mm | 1304*1000*2017mm | ||||
| Package Size (W*D*H) | 630*645*905mm | 810*860*1820mm | 840*860*2050mm | 1355*1000*1980mm | ||||
| Net Weight | 37.5kg | 115kg | 123kg | 378kg | ||||
| Gross Weight | 39.5kg | 132kg | 145kg | 413kg | ||||
