Ultrasonic Cleaners: Advanced Cavitation Technology for Precision Cleaning
Ultrasonic cleaners leverage ultrasonic waves to generate a cavitation effect in the cleaning fluid, creating micro-bubbles that implode to dissolve and decompose dirt, grease, and contaminants. This technology excels at cleaning intricate geometries, including blind holes and internal channels, making it ideal for precision components in various industries.
Key Advantages:
Efficiency: Faster than manual cleaning, with thorough results for even hard-to-reach areas.
Gentle on Surfaces: Non-abrasive process preserves the integrity of delicate parts (e.g., optical lenses, circuit boards).
Labor Savings: Reduces physical effort while ensuring consistent, high-quality cleaning.
Versatile Applications:
Industrial: Hydraulic/pneumatic parts, valves, bearings, oil nozzles, and carburetors.
Electronics: Circuit boards, semiconductor wafers, and electronic components.
Optics & Plating: Optical lenses, audio heads, and plating equipment.
Laboratories: Glassware, scientific instruments, and sample preparation.
Textiles & Chemistry: Polyester filters, spinning nozzles, and fiber plates.
Functional Options:
Choose from models with advanced features to suit your needs:
Temperature Control: Adjustable from RT+5°C to 80°C for enhanced cleaning efficiency (e.g., melting grease).
Power Adjustment: 40%–100% power settings for tailored intensity.
Frequency Options: Single-frequency (40KHz for general cleaning; 28KHz for heavy-duty tasks).
Drainage System: Available in most models for easy liquid disposal.
Compliance & Quality:
International Standards: Built to IEC60886, IEC61102, and IEC61161 for safety and performance.
Imported Components: High-quality parts ensure stable circuits, low noise, and reliable operation.
DT Series Heating Model Specifications
| Model | Inner Tank Dimensions (L/W/H, mm) | Volume (L) | Frequency (KHz) | Ultrasonic Power (W) | Heating Power (W) | Temp Range (°C) | Timing Range (min) | Drainage | Rack Included |
|---|---|---|---|---|---|---|---|---|---|
| SB-100DT | 300×150×100 | 4.5 | 40 | 100 | 200 | RT+5–80 | 1–99 | / | √ |
| SB-120DT | 240×140×100 | 3 | 40 | 120 | 200 | RT+5–80 | 1–99 | / | √ |
| SB-3200DT | 300×155×150 | 6 | 40 | 180 | 400 | RT+5–80 | 1–99 | / | √ |
| SB-5200DT | 300×240×150 | 10 | 40 | 200–300 | 800 | RT+5–80 | 1–99 | √ | √ |
| SB-4200DT | 300×240×200 | 14.4 | 40 | 400 | 800 | RT+5–80 | 1–99 | √ | √ |
| SB-12DT | 500×300×150 | 22.5 | 40 | 500–600 | 1000 | RT+5–80 | 1–99 | √ | √ |
| SB-800DT | 600×300×200 | 30 | 40 | 800 | 1000 | RT+5–80 | 1–99 | √ | √ |
| SB-1000DT | 600×300×300 | 54 | 28 | 1000 | 3000 | RT+5–80 | 1–99 | √ | √ |
| SB-1200DT | 600×400×300 | 72 | 28 | 1200 | 4000 | RT+5–80 | 1–99 | √ | √ |
| SB-2000DT | User-specified size | 120 | 28 | 2000 | 6000 | RT+5–80 | 1–99 | √ | √ |
Important Notice:
Heating Function: Due to thermal lag, the actual tank temperature may be 2–8°C higher than the displayed setting during 恒温超声 (thermostatic ultrasonic) operation. Choose a thermostatic model for precise temperature control.
Models & Designs:
Available in various configurations:
Desktop: Compact for small-scale cleaning (e.g., SB-100DT, SB-120DT).
Industrial-Scale: Large-volume tanks for high-throughput cleaning (e.g., SB-2000DT, SB-3600DT).
With Rack: All models include a stainless steel basket for convenient part placement.
