Cube Ice Machine 80kg 150kg 300kg

CIM-150 CIM-200 CIM-300 CIM-800

The Cube Ice Machine is a high-efficiency commercial-grade appliance designed to produce crystal-clear, hard cube ice for use in laboratories, healthcare facilities.

Features:

1. Eco-friendly&Efficient: fluorine-free high-efficiency compressor with energy-saving refrigeration system.

2. Continuous Ice Production: simple structure with 4 adjustable feet for easy cleaning.

3. Hygienic&Durable: food-grade stainless steel exterior, stylish and easy to maintain.

4. Fully Automated Operation: smart control system for automatic water intake, ice-making, ice release, storage, and shutdown when full.

5. Dual Independent Cooling Systems: energy-saving design allows separate operation of each unit.

6. Ideal for scientific research labs and seafood preservation.

Usage Notes:

1. Water Supply: connect to tap water(0.2~0.7MPa pressure required).

2. Ventilation Space: ≥100mm clearance on both sides; ≥150mm clearance at the rear.

3. Maintenance: clean the condenser every 6 months to ensure optimal cooling and longevity.

Technical Parameters:

Model CIM-150 CIM-200 CIM-300 CIM-800
Ice Making Capacity(kg/24h) 150 200 300 800
Max. Ice Storage Capacity 80kg 150kg 300kg
Ice Shape Cube ice: 22*22*22mm
Way of Condensation Air/water-cooling Water-cooling
Ambient Temperature 5~40℃
Compressor Tecumseh Enhance/Tecumseh
Refrigerant R404a, 0.7kg R404a, 0.8kg R404a, 0.95kg R404a, 1.1kg
Standard Accessory Ice scoop*1, water inlet hose*1, drain hose*1, spare sealing washer*1
Consumption 750W 1300W 1600W 3200W
Power Supply AC220V, 50Hz(Standard); 110V, 50/60Hz, 220V, 60Hz(Optional) AC380V, 50Hz
External Size(W*D*H) 560*830*1520mm 560*830*1620mm 760*830*1850mm 1230*960*1950mm
Package Size(W*D*H) Main Machine 770*780*800mm 915*795*980mm 1350*835*1035mm
Ice Storage Bin 800*640*980mm 870*790*1020mm 1270*985*1130mm
Gross Weight Main Machine 56kg 60kg 70kg 160kg
Ice Storage Bin 37kg 47.5kg 78kg
