Features:
1. Capacitive touch screen
High sensitivity color LCD capacitive touch screen, clear color, smooth operation and detailed display. Toughened glass screen, durable, high transparency.
2. One-body water bath
Adopt the injection molding integrated PC water bath, no circulation dead Angle, high strength, high temperature resistance, easy to clean, the deficiency of PMMA in strength, temperature and life was avoided.
3. Illuminating system
With a patented lighting system of 1, it is convenient to observe the sample disintegration, and the fog surface is astigmatized to avoid stimulating the user’s vision, while illuminating the entire beaker.
4. Quickly remove and install the hanging basket card
With patent 2, it can quickly disassemble and install and adjust the height of the hanging basket card, which integrates positioning, height adjustment, fastening and a whole body. It can realize the quick reading and dismounting of the hanging basket, which is convenient and practical.
5. Full size screen
Provide 2mm, equipped with 1mm, 0.71mm, and 0.42mm sieve mesh are selected to meet different user’s requirements.
6. High precision temperature sensor
German imports of 1/3 b (highest level) and high precision Pt1000 platinum resistance temperature sensor, good linear, low temperature drift, quick response, high precision, at the same time using ptfe sheathed with temperature compensation, super soft, pure copper, silver, high temperature resistant AFR250 cable. The water bath temperature can be feedback more quickly and accurately.
7. Inside the cup correction
The temperature correction in the cup is adopted to avoid the error caused by the temperature correction in the tank of the traditional caving instrument.
Parameters
1. Three baskets disintegration time detection system
2. High precision PT1000 temperature sensor
3. Temperature correction in cup
4. The test time can be adjusted
5. Real-time display of time temperature
6. Overheating protection
7. Integral water bath box, no water bath circulation dead Angle, easy to clean
8. Overall appearance design, high – grade simplicity
9. Independent lighting system
10. Voice prompt
11. One-piece, quick removal of hanging basket card
12. High sensitivity capacitive touch screen
13. Authority management
14. Audit trails
Technical indicators
| Temperature range | Indoor temperature-45℃ |
| Temperature resolution | 0.01℃ |
| Number of hanging basket | 3 |
| Lift frequency | 30-32 times/min |
| Lifting distance | 55mm±1mm |
| Spacing between bottom and bottom of screen | 25mm±2mm |
| Mesh size | 2mm, optional 1mm,0.71mm,0.42mm |
| Block density | 1.18-1.2g/cm |
| Number of users | 7 |
| User level | 3 |
| Record keeping | 96*366days |
