Features
Equipped with new software and centralized microcomputer control system
7-inch TFT touch screen for intuitive and convenient operation
Ultrasonic power continuously adjustable in 1% increments
Supports pulse operation, continuous operation, and test mode
Precise time control: ultrasonic time, interval time, and total time adjustable to 0.1 seconds
Main Technical Parameters
| Parameter | JY96-IIN | JY88-IIN | JY88-PRO | JY92-IIN | JY92-IIDN |
|---|---|---|---|---|---|
| Frequency | 20-25 kHz | 20-25 kHz | 20-25 kHz | 20-25 kHz | 20-25 kHz |
| Display Type | 7-inch touch screen | 7-inch touch screen | 7-inch touch screen | 7-inch touch screen | 7-inch touch screen |
| Power | 150 W (1%-100%) | 250 W (1%-100%) | 450 W (1%-100%) | 650 W (1%-100%) | 900 W (1%-100%) |
| Standard Probe | 6 mm | 6 mm | 6 mm | 6 mm | 6 mm |
| Optional Probes | 3 mm | 3 mm | 3 mm | 2 mm, 3 mm, 10 mm | 2 mm, 3 mm, 10 mm, 12 mm, 15 mm |
| Disruption Volume | 10-100 ml | 10-200 ml | 10-200 ml | 100 μl-500 ml | 100 μl-600 ml |
| Duty Ratio | 0.1-99.9% | 0.1-99.9% | 0.1-99.9% | 0.1-99.9% | 0.1-99.9% |
| Temperature Alarm | 0-99.9℃ (Prevents sample overheating) | 0-99.9℃ (Prevents sample overheating) | 0-99.9℃ (Prevents sample overheating) | 0-99.9℃ (Prevents sample overheating) | 0-99.9℃ (Prevents sample overheating) |
| Alarm Functions | Time, overload protection | Time, overload protection | Time, overload protection | Time, overload protection | Time, temperature, overload protection |
| Power Supply Chassis Dimensions (L×W×H) | 430×245×300 mm | 430×245×300 mm | 430×245×300 mm | 430×245×300 mm | 430×245×300 mm |
| Total Weight (Host + Transducer) | 8.4 Kg | 8.5 Kg | 8.5 Kg | 9.5 Kg | 9.6 Kg |
| Soundproof Enclosure Dimensions (L×W×H) | 345×345×535 mm | 345×345×535 mm | 345×345×535 mm | 345×345×535 mm | 345×345×535 mm |
