DTY Series Multi-Frequency Ultrasonic Cleaner
Designed to meet diverse industrial and laboratory needs, the DTY series multi-frequency ultrasonic cleaner integrates adjustable ultrasonic power, frequency, and timing to deliver versatile cleaning and processing capabilities. Unlike traditional single-frequency machines, it supports multi-frequency conversion (25KHz, 28KHz, 40KHz, 59KHz), enabling a full cleaning cycle-from rough pre-wash to precision rinse-within a single unit. This eliminates stubborn residues in complex geometries, making it ideal for applications requiring thorough cleanliness, such as jewelry, dental, and medical equipment cleaning.
Key Functions
Multi-Purpose Capability: Suitable for cleaning, decentralized extraction, nano-preparation, chemical reactions, degassing, defoaming, emulsification, and mixing.
Frequency Flexibility: Switch between frequencies for different stages of cleaning:
25KHz/28KHz: Heavy-duty cleaning for tough contaminants (e.g., grease, casting residues).
40KHz/59KHz: Precision cleaning for delicate surfaces (e.g., jewelry, surgical instruments).
Main Features
Intuitive Control: Backlit LCD screen with microcomputer memory for storing custom parameters.
Independent Timing: Ultrasonic working time adjustable (0–99 minutes) with countdown display.
Temperature Management: Real-time display of cleaning tank temperature (ambient–80°C) with adjustable heating.
Durable Design: Stainless steel shell, cover, and included basket; sound-dampening cover for quiet operation.
Convenient Operation: Single-chip controller and built-in drainage function for easy liquid disposal.
Technical Specifications
| Model | Inner Tank Dimensions (L/W/H, mm) | Volume (L) | Frequencies (KHz) | Ultrasonic Power (W) | Heating Power (W) | Drainage |
|---|---|---|---|---|---|---|
| SB-300DTY | 300×240×150 | 10 | 25/28/40/59 | 300 | 320 | ✔ |
| SB-400DTY | 300×240×200 | 15 | 25/28/40/59 | 400 | 320 | ✔ |
| SB-500DTY | 500×300×150 | 22.5 | 25/28/40/59 | 500 | 600 | ✔ |
| SB-600DTY | 500×300×200 | 30 | 25/28/40/59 | 600 | 3000 | ✔ |
| SB-1000DTY | 600×300×300 | 54 | 25/28/40/59 | 1000 | 4000 | ✔ |
| SB-1200DTY | 600×400×300 | 70 | 25/28/40/59 | 1200 | 4000 | ✔ |
Applications
Jewelry Industry:
Retail/Wholesale: Tabletop models for cleaning rings, watches, and chains (individual or bulk).
Manufacturing: Removing casting residues, buffing compounds, and grease from chain components.
Dental Labs:
Deep cleaning of dental instruments; gentle cleaning of cosmetic mouthpieces with adjustable power.
Medical/Surgical:
Sterilizing surgical tools and artificial components; compatible with disinfectant chemicals.
Tattoo Industry:
Cleaning needles, nozzles, brushes, and filters to maintain hygiene standards.
Advantage
The DTY series redefines cleaning efficiency by combining multi-frequency technology with intelligent controls, making it an essential tool for industries where precision and cleanliness are non-negotiable. Whether for bulk industrial use or delicate laboratory tasks, these machines deliver consistent, residue-free results.
Contact us to explore how the DTY series can optimize your cleaning processes.
