Features:
1. The housing is made of cold-rolled steel plate with electrostatic spray coating, and the inner chamber has rounded corners for easy cleaning.
2. The door and chamber are sealed with a specially designed silicone gasket to maintain vacuum, while allowing easy opening in non-vacuum conditions.
3. The temperature control system uses a microcomputer PID design with an intelligent color LCD display, providing precise temperature regulation, timing, and over-temperature alarm functions.
4. The double-layered glass door allows clear observation of items inside the chamber.
Technical Parameters:
| Model |
BJPX-ZK25A |
BJPX-ZK50A |
BJPX-ZK25B |
BJPX-ZK50B |
| Capacity |
25L |
50L |
25L |
50L |
| Temp. Range |
RT+10~250℃ |
| Temp. Resolution |
0.1℃ |
| Vacuum Degree |
＜133Pa |
| Working Chamber Material |
201 stainless steel |
304 stainless steel |
| Standard Accessory |
Shelf*2, vacuum tube |
| Optional Accessory |
Vacuum pump: 2XZ-2(AC220V, 50Hz; 220V, 60Hz; 110V, 60Hz), printer, RS485 interface, remote control function, USB interface, programmable temperature controller |
| Consumption |
600W |
1400W |
600W |
1400W |
| Power Supply |
AC220V, 50/60Hz(Standard); 110V, 50/60Hz(Optional) |
| Internal Size(W*D*H) |
300*300*275mm |
415*370*345mm |
300*300*275mm |
415*370*345mm |
| External Size(W*D*H) |
595*455*455mm |
720*555*535mm |
595*455*455mm |
720*555*535mm |
| Package Size(W*D*H) |
670*530*550mm |
770*630*620mm |
670*530*550mm |
770*630*620mm |
| Net Weight |
40kg |
59kg |
40kg |
59kg |
| Gross Weight |
45kg |
65kg |
45kg |
65kg |
