Vertical Autoclave BKQ-B II

BKQ-B50II, BKQ-B75II, BKQ-B100II, BKQ-B120II, BKQ-B150II, BKQ-B200II

It is widely used in laboratories, inspection departments, food processing enterprises, etc. for sterilization of equipment and medical waste. It uses gravity displacement to discharge the cold air in the sterilization chamber to ensure the sterilization effect.

Category Tag

Features:

1. The hand wheel slides to open the door, which is fast and labor-saving.

2. Casters facilitate the movement of the equipment.

3. It has a fast maintenance window, and the electrical part does not need to remove the cover for maintenance.

4. Steam generation method: heating inside the main body, no external steam source is required.

5. Self-expanding silicone sealing ring has good sealing effect and long service life.  It is molded with transparent medical silicone.

6. Real-time detection and display of the temperature in the sterilization chamber, with a display accuracy of 0.1℃.

7. The LED digital tube displays temperature, time, alarm code and the indicator light shows the current operating status.

8. Using gravity displacement and positive pressure pulsating exhaust method to discharge the cold air in the load and sterilization room.

9. Optional printer to record the temperature during sterilization.

10. Inner water tank: Standard for BKQ-B50/75/100/120II; Optional for BKQ-B150/200(II).

11. A variety of programs

There are exposed program, packaging program, rubber program, dressing program, liquid program, liquid customization, solid customization.

Technical Parameters:

Model BKQ-B50II BKQ-B75II BKQ-B100II BKQ-B120II BKQ-B150(II) BKQ-B200(II
Capacity 50L 75L 100L 120L 150L 200L
Designed Pressure 0.28MPa 0.3MPa
Working Pressure 0.23MPa 0.217MPa
Designed Temp. 150℃ 137℃
Working Temp. 105~136℃ 50~134℃
Temp. Precision 0.1℃
Chamber Material S30408
Chamber Size φ386*514mm φ386*695mm φ386*875mm φ386*1055mm φ500*760mm φ500*1000mm
Basket/Mesh Bottom Basket/Bucket φ365*360mm, 1pc φ365*265mm, 2pcs φ365*360mm, 2pcs φ365*360mm, 1pc

φ365*265mm, 2pcs

φ470*230mm, 3pcs φ470*230mm, 4pcs
Noise ≤65dB
Altitude ≤2700m
Standard Accessories Basket
Optional Accessories Printer, mesh bottom basket, bucket Printer
Consumption 4.4KW 4.7KW 5.2KW 5.2KW 6KW
Power Supply AC220V, 50/60Hz(Standard); AC110V, 50/60Hz(Optional) AC380V, 50/60Hz(Standard);

AC220V, 50/60Hz(Optional)

External Size(W*D*H) 640*550*980mm 640*550*1080mm 640*550*1280mm 640*550*1380mm 630*700*1400mm 630*700*1600mm
Net Weight 87kg 95kg 105kg 122kg 162kg 180kg
Package Size(W*D*H) 750*745*1100mm 750*745*1240mm 750*745*1450mm 750*745*1540mm 760*800*1530mm 760*800*1720mm
Gross Weight 104kg 114kg 127kg 142kg 213kg 238kg
