Washer Disinfector Lab Automatic Glassware Washer

BKX-CQS-120, BKX-CQZ-120, BKX-CQS-220, BKX-CQS-320

Laboratory botle washing machine is a kind of automatic equipment specially used for cleaning laboratory utensis, which is widely used in chemical industry, food testing, scientific research and other fields. Through high temperature, high pressure water flow and special cleaning agent, it efficiently removes residues, ensures the cleanliness of utensils meets the experimental requirements, replaces the traditional manual cleaning, improves eficiency and reduces the risk of cross contamination.

Features:

1. Adopt PLC microcomputer control technology. Standard printer and 7-inch color LCD touch screen.

2. Complete protection functions: The door cannot be opened during operation to ensure safe use; dual temperature protection of water temperature and air temperature; power failure protection function; water seal design of drainage pipeline to prevent reverse flow of sewage; installed with leak-proof detection, if liquid leakage is detected, The program is cancelled, the inlet valve is closed, and the drain pump is started.

Cleaning Procedure:

1. Standard procedure: Meet the general contaminant blood cleaning.

2. Quick cleaning program: Meet the cleaning of lightly polluted utensils.

3. Customized cleaning program: According to different cleaning needs, users can customize the combined cleaning program.

4. Drying program: Equipped with a high-performance drying system, which can quickly complete the drying and cleaning of various instruments.

5. Manual test procedure: Self-check the operation status of each component of the equipment.

Cleaning Racks:
QQ截图20250618132349QQ截图20250618132403

Technical Parameters:

Model

BKX-CQS-120 BKX-CQZ-120 BKX-CQS-220 BKX-CQS-320
Cleaning Capacity 120L 120L 220L 320L
Washer Load Level 1 1 2 3
Water Wash Power 0.75KW 0.75KW 1.5KW 1.5KW
Water Heater Power 5KW 5KW 7KW 7KW
MAX. Power 6KW 6KW 9KW 9KW
Water Consumption/Step (L) 15 15 20 20
Tank Internal Temperature 0~95℃
Water Supply Pressure Tap water: 0.3~0.8Mpa
pure water: 0~0.8Mpa
Peristaltic Pump for Cleaning Agent 2
Cleaning Agent Level Sensor YES
Washing Pump Sweden 430L/min Sweden 430L/min Sweden 1000L/min Sweden 1000L/min
Standard Cleaning Racks BKXIR36, 1pc
Drying Drying Function YES
Steam Condenser YES
Dry Power 3KW 3KW 4KW 4KW
Control System and Traceability Control System 7″ color LCD touch screen display, microprocessor
Cleaning Program 12 pre-set programs+4 PLC free programming
Password Protection YES
Safety Emergency Button YES
USB port YES
Integrated printer YES
Online Monitor Performance of Washing NO
Dimensions& Weight Chamber Dimension (W*D*H) 600*620*560mm 600*650*560mm 600*630*730mm 600*630*930mm
Exterior Dimension (W*D*H) 980*740*870mm 890*800*1540mm 690*820*1800mm 690*820*2000mm
Package Dimension (W*D*H) 1150*940*1060mm 1100*970*1900mm 850*1000*2250mm 850*1000*2250mm
Net Weight (Host only) 190kg 260kg 290kg 310kg
Gross Weight (Host with rack) 220kg 290kg 330kg 350kg
Others Door Double-layered glass door, 304 stainless steel Double-layered glass door,  304 stainless steel Double-layered glass door,  304 stainless steel Double-layered glass door,  304 stainless steel
Safety Door Lock YES YES

YES

YES
Built-in RO Water Pump YES YES YES YES
Noise <50dB
Power Supply AC220V, 50Hz(Standard)
AC220V, 60HZ; 110V, 50/60HZ(Optional)
